Hangzhou Ocean Industry Co., Ltd. Xitoyda txf seriyali sayyora konuslari-diskli qadamsiz tezlik oʻzgartirgichlarining yetakchi ishlab chiqaruvchilari va yetkazib beruvchilaridan biri hisoblanadi. Fabrikamızdan Xitoyda ishlab chiqarilgan ulgurji mustahkam sanoat zanjirlari va elektr uzatish qismlariga xush kelibsiz. Barcha tayyorlangan mahsulotlar yuqori sifat va raqobatbardosh narxga ega.
TXF Series Planet Cone{0}}disk Stepless Speed Variator sozlanishi chiqish tezligiga muhtoj boʻlgan har qanday vazifa uchun ideal tanlovdir. Bu qurilmalar qarama-qarshi yoʻnalishda harakatlanadigan va dvigatel, fan yoki boshqa gadjet tezligini tartibga solishga qodir boʻlgan ikkita konussimon diskdan iborat. Ular, shuningdek, texnik xizmat ko'rsatishsiz{3}}mexanik tezlikni o'zgartiruvchi-bir umrlik moylash tizimi bilan birga keladi.
Parametr
| Variatorning asosiy xarakteristikalari jadvali | ||||||||
| Quvvat | Model | n2 maks | n2 min | M2 min | M2 maks | Skip ehtimol % | Haroratning ko'tarilishi; daraja | |
| 1400 | 0,25KVt/4P | TXF005/071 | 1000 | 170 | 2 | 6 | 3-8.8 | 46 |
| 0,37KVt/4P | TXF005/071 | 1000 | 170 | 3 | 6 | 3-8.8 | 46 | |
| 0,55KVt/4P | TXF010/080 | 1000 | 170 | 4.4 | 12 | 3-8.8 | 46 | |
| 0,75KVt/4P | TXF010/080 | 1000 | 170 | 6 | 12 | 3-8.8 | 46 | |
| 1,1KVt/4P | UD1.1 | 950 | 165 | 9 | 18 | 3-8.8 | 46 | |
| 1,5KVt/4P | UD1.5 | 950 | 165 | 12 | 24 | 3-8.8 | 46 | |
| 2,2KVt/4P | UD2.2 | 1000 | 200 | 18 | 36 | 3-8.8 | 46 | |
| 3KVt/4P | UD3 | 1000 | 200 | 24 | 48 | 3-8.8 | 46 | |
| 4KVt/4P | UD4 | 1000 | 200 | 32 | 64 | 3-8.8 | 46 | |
| 5,5 KWI4P | UD5.5 | 1000 | 200 | 45 | 90 | 3-8.8 | 50 | |
| 7,5KVt/4P | UD7.5 | 1000 | 200 | 59 | 118 | 3-8.8 | 50 | |
| Asosiy model va birinchi vites reduktori uchun ishlash parametri | |||||
| TYPE | Mos keladigan motor | Chiqish tezligi r/min | Chiqish momenti N,m | Og'irligi kg | |
| TYPE | KUCH KVt | ||||
| TXF005/071-40D | Y2-712-4B5 | 0.37 | 190-32 | 15-30 | |
| TXF010080-40D | Y2-802-4B5 | 0.75 | 30-59 | ||
| B | D (k6) | G | G3 | M | N (h8) | O | P | T | |
| 005/071 | 30(40) | 14(19) | 107 | 57 | 130 | 110 | 9 | 160 | 3.5 |
| 010/080 | 40(50) | 19(24) | 131 | 68.5 | 165 | 130 | 11 | 200 | 3.5 |
| VC | VF | VL | VR | VS | b | f | t | kg | |
| 005/071 | 79.5 | 104.5 | 82 | 116.5 | 71 | 5(6) | M6(M6) | 16(21.5) | 33 |
| 010/080 | 89.5 | 127 | 103 | 126.5 | 85 | 6(8) | M6(M8) | 21.5(27) | 6.1 |
| kg: Dvigatelning og'irligini hisobga olmaganda ( ) Diametr moslashtirilgan reduktor uchun | |||||||||
| Dvigatel qo'llaniladi | |
| Y2IMB5 | |
| TXF005 | 071 |
| TXF010 | 080 |
| Turi | O'rnatish uchun shakl va o'lcham | |||||||||||||||||
| A | A1 | A2 | B | B1 | bl | c1 | d0 | d1(k6) | e1 | H | H1 | H2 | k | L | L2 | O | R | |
| TXF005071-40D | 112 | 64 | 4 | 190 | 148 | 8 | 27 | 12 | 24 | 30 | 201 | 131 | 165.5 | 155 | 48D | 255 | 48 | 110 |
| TXF010080-40D | 130 | 70 | 10 | 212 | 165 | 8 | 31 | 14.5 | 28 | 60 | 248.5 | 162 | 206 | 188 | 565.5 | 310.5 | 59 | 120 |
| Turi | O'rnatish uchun shakl va o'lcham | |||||||||||||||||
| A | A1 | A2 | B | B1 | bl | c1 | d0 | d1(k6) | e1 | H | H1 | H2 | k | L | L2 | O | R | |
| TXF005071-40D | 112 | 64 | 4 | 190 | 148 | 8 | 27 | 12 | 24 | 30 | 201 | 131 | 165.5 | 155 | 48D | 255 | 48 | 110 |
| TXF010080-40D | 130 | 70 | 10 | 212 | 165 | 8 | 31 | 14.5 | 28 | 60 | 248.5 | 162 | 206 | 188 | 565.5 | 310.5 | 59 | 120 |
| Model | A | C | D(H8) | E | F | G | G1 | G3 |
| TXF0.25-NMRV040 | 70 | 100 | 8 | 121.5 | 43 | 177 | 78 | 127 |
| TXF0.25-NMRV050 | 80 | 120 | 25 | 144 | 9 | 187 | 92 | 137 |
| TXF0.37-NMRV050 | 187 | 137 | ||||||
| TXF0.37-NMRV063 | 100 | 144 | 25 | 174 | 67 | 202 | 112 | 152 |
| TXF0.55-NMRV063 | 226 | 163.5 | ||||||
| TXF0.75-NMRV063 | 120 | 163.5 | ||||||
| TXF0.37-NMRV075 | 120 | 172 | 8 | 205 | 72 | 219.5 | 120 | 169.S |
| TXF0.55-NMRV075 | 243.5 | 181 | ||||||
| TXF0.75-NMRV075 | 243.5 | 181 | ||||||
| UD1.1-NMRV075 | 270.5 | 213.3 | ||||||
| UD1.5-NMRV075 | 281.5 | 216.5 | ||||||
| TXF0.55-NMRV090 | 140 | 206 | 3$ | 238 | 74 | 260.3 | 140 | 198 |
| TXF0.75-NMRV090 | 260.5 | 198 | ||||||
| UD1.1-NMRV090 | 287.5 | 230.5 | ||||||
| UD1.5-NMRV090 | 298.5 | 33.5 | ||||||
| UD1.1-NMRV110 | 170 | 252.5 | 42 | 295 | 一 | 118 | 155 | 261 |
| UD1.5-NMRV110 | 329 | 264 | ||||||
| UD2.2-NMRV110 | 368 | 291 | ||||||
| UD3.0-NMRV110 | 368 | 291 | ||||||
| UD4.0-NMRV110 | 368 | 291 | ||||||
| UD1.5-NMRV130 | 200 | 292.5 | 45 | 335 | 一 | 349 | 170 | 284 |
| UD2.2-NMRV130 | 388 | 311 | ||||||
| UD3.0-NMRV130 | 388 | 311 | ||||||
| UD4.0-NMRV130 | 388 | 311 |
| Model | VF | VL | VR | VRI | K | KE | a | KA |
| TXF0.25-NMRV04 | 144.5 | 122.5 | 116..5 | 116.5 | 60 | M6XB (n-4) | 45 daraja | 72 |
| TXF0.25-NMRV05 | 154.5 | 132.5 | 116.5 | 116.5 | 70 | M8X10 (n-4) | 45 daraja | 90 |
| TXF0.37-NMRV05 | 154.5 | 131.5 | 116.5 | 116.5 | ||||
| TXF0.37-NMRV06 | 167.5 | 145.5 | 116.5 | 116.5 | 85 | MBXI4(n-4) | 45 daraja | 102 |
| TXF0.55-NMRV06 | 190 | 166 | 126.5 | 1265 | ||||
| TXF0.75-NMRV06 | 190 | 106 | 126.5 | 12065 | ||||
| TXF0.37-NMRV07 | 179.5 | 1575 | 126.3 | 126.5 | 90 | M8X14 (n-4) | 45 daraja | 102 |
| TXF0.55-NMRV07 | 202 | 178 | 1263 | 1265 | ||||
| TXF0.75-NMRV07 | 201 | 178 | 126.5 | 126.5 | ||||
| UD1.1-NMRV075 | 203 | 184 | 13S | 一 | ||||
| UD1.5-NMRV075 | 221 | 202 | 135 | 一 | ||||
| TXF0.55-NMRV090 | 217 | 193 | 126.5 | 1265 | 10 0 | M10X18 (n-8) | 45 daraja | 111 |
| TXF0.75-NMRV090 | 217 | 193 | 126.5 | 1265 | ||||
| UD1.1-NMRV090 | 218 | 199 | 1DS | 一 | ||||
| UD1.5-NMRV090 | 236 | 217 | 11S | 一 | ||||
| UD1.1-NMRV110 | 218 | 219 | 126.5 | 一 | 11 5 | M10X18 (n-8) | 45 daraja | 131 |
| UD1.5-NMRV110 | 256 | 237 | 135 | 一 | ||||
| UD2.2-NMRV110 | 291 | 268 | 160 | 一 | ||||
| UD3.0-NMRV110 | 291 | 268 | 166 | 一 | ||||
| UD4.0-NMRV110 | 291 | 268 | 166 | 一 | ||||
| UD1.5-NMRV130 | 176 | 257 | 135 | 一 | 12 0 | M12X21 (n-8) | 45 daraja | 144 |
| UD2.2-NMRV130 | 311 | 288 | 166 | 一 | ||||
| UD3.0-NMRV130 | 311 | 288 | 166 | 一 | ||||
| UD4.0-NMRV130 | 3H1 | 288 | 166 | 一 |
| KB | KC | a1 | KM | KN (H8) | KO | KP | KQ | b | t | Kg |
| 7 | 4 | 45 daraja | 87 | 60 | 9(m4) | 10 | 9 | 6 | 208 | |
| 9 | 5 | 45 daraja | 90 | 70 | 11(m4) | 125 | 110 | 8 | 283 | |
| 10 | 6 | 45 daraja | 150 | 15 | 11(m4) | 180 | 142 | 8 | 783 | |
| 13 | 6 | 45 daraja | 165 | 130 | 14(m4) | 200 | 170 | 8 | 313 | |
| 13 | 6 | 45 daraja | 175 | 152 | 14(m4) | 210 | .000 | 10 | 383 | |
| 15 | 6 | 45 daraja | 230 | 170 | 14(n8) | 2380 | 260 | 12 | 453 | |
| 15 | 6 | 22,5 daraja | 255 | 19 | 16(n8) | 330 | 290 | 14 | 48.8 |
